E2H060-Z-395N Threaded Cartridge Balance Valve
E2H060-Z-395N High Precision Control Valve
1. General Introduction
The E2H060-Z-395N is a high-performance threaded cartridge balance valve, the same as Parker's renowned E2 series. It is designed to meet the demanding requirements of various motion control applications, providing reliable flow control and pressure management solutions.
2. Structural Design
- Valve Structure: It features a poppet-type construction, which ensures minimal leakage. Inside the valve, there is a direct-acting relief valve integrated for overload protection. Additionally, a built-in check valve is included, optimizing space utilization and reducing installation costs.
- Material and Finish: The working parts of the valve are hardened to achieve maximum durability. All external components are likely to be zinc-plated, enhancing corrosion resistance and ensuring a long service life even in harsh environments.
3. Performance Features
- Excellent Control Performance: The E2H060-Z-395N offers good control performance and stability. It may provide multiple pilot ratios, making it adaptable to different application scenarios, such as cylinder control and motor control.
- Wide Operating Range: Suitable for use with mineral-based or synthetic oils with lubricating properties.
4. Specification Parameters
- Adjustment Method: It adopts a Z-type screw adjustment as standard, allowing for precise control of the valve's performance.
- Flow Parameters: The rated flow at 7 bar (100 psi) pressure is 395 (as indicated by the number 395 in the model). At a 300 psi pressure differential and with the coil fully de-energized, the rated flow corresponds to a pressure of 44 bar (640 psi).
- Pressure Range: The maximum pressure setting is related to the N-type nitrile rubber seal, which can withstand pressures in the range of 50-350 bar (725-5000 psi).
5. Application Scenarios
This threaded cartridge balance valve is widely used in industrial hydraulic systems, mobile machinery, and other applications where precise control of fluid flow and pressure is required. It can effectively prevent overspeed and ensure the safe and stable operation of equipment.
In conclusion, the E2H060-Z-395N threaded cartridge balance valve combines advanced design, high-quality materials, and excellent performance, making it an ideal choice for a variety of motion control applications.
